30KW 37KW Heavy Duty Inverter AC Drive For Fan Speed Controller

    Buy cheap 30KW 37KW Heavy Duty Inverter AC Drive For Fan Speed Controller from wholesalers

    Buy cheap 30KW 37KW Heavy Duty Inverter AC Drive For Fan Speed Controller from wholesalers
    • Buy cheap 30KW 37KW Heavy Duty Inverter AC Drive For Fan Speed Controller from wholesalers
    • Buy cheap 30KW 37KW Heavy Duty Inverter AC Drive For Fan Speed Controller from wholesalers

    30KW 37KW Heavy Duty Inverter AC Drive For Fan Speed Controller

    Ask Lasest Price
    Brand Name : STABLECU
    Model Number : ST310-4T30G-37G
    Certification : CE
    Price :
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability :
    Delivery Time : 5-8 days
    • Product Details
    • Company Profile

    30KW 37KW Heavy Duty Inverter AC Drive For Fan Speed Controller

    30KW 37KW 50 To 60HZ Frequency Converter AC Drive For Fan Speed Controller

    Quick details of frequency inverter

    Model310-4T30G
    Rated Voltage3 phase AC 380V-480V
    Output Frequency Range0-300hz
    Control ModeV/F Control
    Product NameAC Drive
    Input Voltage380V
    Input Frequency50/60HZ
    Output Frequency0-300HZ
    Warranty18 months

    Introduction of frequency inverter
    ST310 series inverter adopts vector control technology, has excellent drive and control performance,
    rich hardware configuration and software function improves usability and reliability, and meets different
    industrial applications. 0.75 ~ 22KW built-in standard brake unit, 30 ~ 110KW optional built-in brake unit,
    independent cooling air duct design, and thousands of revolutions of the fan, improve product stability and
    performance, extend product life, improve product quality Competitiveness.
    Model specification and technical data of frequency inverter

    Frequency converter ModelThe power rating(kW)The output current(A)The input current(A)Adaptation motor(kW)The braking unit
    ST310-4T0.75GB0.752.33.40.75




    The standard built-in

    ST310-4T1.5GB1.53.85.01.5
    ST310-4T2.2GB2.25.56.02.2
    ST310-4T3.7GB3.79.010.53.7
    ST310-4T5.5GB5.51314.65.5
    ST310-4T7.5GB7.51720.57.5
    ST310-4T11GB11242911
    ST310-4T15GB15303515
    ST310-4T18.5GB18.5394418.5
    ST310-4T22GB22455022
    ST310-4T30G30606530



    optional
    built-in

    ST310-4T37G37758037
    ST310-4T45G45919545
    ST310-4T55G5511211855
    ST310-4T75G7515015775
    ST310-4T90G90176160*90
    ST310-4T110G110210192*110
    ST310-4T132G132253232*132Built-out
    ST310-4T160G160310285*160
    ST310-4T185G185350326*185
    ST310-4T200G200380354*200
    ST310-4T220G220430403*220
    ST310-4T250G250470441*250
    ST310-4T280G280520489*280
    ST310-4T315G315590571*315
    ST310-4T355G355650624*355
    ST310-4T400G400725699*400
    ST310-4T450G450755770*450
    * 185KW ~ 450KW products are equipped with external DC reactor. Please be sure
    to connect the reactor to use, otherwise the product will not be able to operate normally

    Detailed images of frequency inverter

    30KW 37KW Heavy Duty Inverter AC Drive For Fan Speed Controller
    30KW 37KW Heavy Duty Inverter AC Drive For Fan Speed Controller

    30KW 37KW Heavy Duty Inverter AC Drive For Fan Speed Controller
    FAQ

    1. Who are we?
    We are a manufacturer based in Guangdong, China, start from 2009, sell to Domestic Market(100.00%).
    There are total about 201-300 people in our office.
    2. How can we guarantee the quality?
    Always a pre-production sample before mass production; Always final Inspection before shipment.
    3. What can you buy from us?
    Ultrasonic Generator, PLC/Motion Controller, Servo Motor And Stepper Motor, Frequency Converter,
    Automation System Development And Complete Set Of Electric Box.
    4. Do you offer customization services?
    Yes, we can customize the products according to your requirements. Please send us an inquiry, your inquiry
    will be replied within 12 hours.
    5. What services can we provide?
    Accepted Delivery Terms: FOB, CFR, CIF, EXW, DDP, DDU, Express Delivery;
    Accepted Payment Currency: USD, EUR, JPY, CAD, AUD, HKD, CNY;
    Accepted Payment Type: T/T, L/C, D/P D/A, MoneyGram, Credit Card, PayPal, Western Union, Cash;
    Language Spoken: English, Chinese.
